Oil & Gas
Zero-Leakage Isolation in Hydrocarbon Service
Oil & Gas facilities face demanding conditions – high pressures, sour media, and nonstop production. Vestra Valve’s SG-1 line is engineered with rocket-applied chromium-carbide seating, robust mounting brackets, and in-line repairability to deliver dependable, long-life service in the harshest energy environments.
Applications:
• Offshore production systems
• Midstream crude and gas transport
• Gas dehydration and compression
• Utility isolation and emergency shutdowns
Why Vestra for Oil & Gas: At Vestra, every valve is machined, coated, assembled, and tested in Houston, Texas. Owning the full process means tighter quality control, faster response when replacements are needed, and valves that live up to their promise. In Oil & Gas, failure is never an option; and with Vestra, it isn’t.
Features & Benefits
Available sizes
- 1" (25DN)-24" (600Dn)
- Up to 2500
End connections
- Socketweld
- Buttweld
- Flanged (Upon Request)
- Threaded (Upon Request)
- Ring Joint
Body materials
- ASME B16.34
- PED*
- TSG*
- NACE-MR-01-75
Seating components
- Rocket applied, Chromium Carbide coatings
- Industry leading hardness, resistant to erosion, corrosion, and thermal shock
- Constant contact seating surfaces protected from flow
- Mate-Lapped for full, 100% contact seating surfaces
- Pressure assist seating and high strength Belleville Spring ensure zero-leakage shutoff at all pressure differentials
In-line repairability
- Split Body Design allows for full replacement of all critical seating components without removal of actuation
Operating mechanisms
- Integral T-Shoulder blowout proof stem
- Live-Loaded Packing and 1/4 turn operation for zero fugitive Leakage and minimal wear and tear
- Robust mounting bracket supports all actuation methods in any position
- Extended mounting bracket accommodates power industry practices for high temperature insulation thickness
- Hard stops on the mounting bracket prevent actuation overtravel and guaranties a perfect ball and seat alignment in the open position
